Premium
Quality CFX96 Optical Reaction Module for Real-Time PCR Systems
CFX96 Optical Reaction
Module for Real-Time PCR Systems
Use the CFX96 Optical
Reaction Module for precise, reproducible real-time PCR. The optical module
includes an optical system for collection of fluorescent data and a thermal
cycler block. SYBR® Green Supermix, 96-well PCR plates and plate seals are
included.
The CFX96 Optical
Reaction Module is a member of the family of interchangeable reaction modules
that can be used with the C1000 Touch Thermal Cycler Chassis for PCR and
real-time PCR. All modules can be quickly inserted and removed from the cycler
chassis without tools.
Features and Benefits
When the CFX96 Optical
Reaction Module is combined with the thermal cycler chassis, the system offers:
·
Detection
of up to 5 targets per well, plus a channel dedicated to singleplex FRET
·
Protocol
autowriter that generates an optimal protocol for your reaction components
·
Thermal
gradient feature that identifies optimal annealing temperature in a single
run
·
The
CFX96 Touch Real-Time PCR Detection System has six independently controlled
thermal electric units providing even, precisely controlled temperatures at all
times during the run, including ramping. The reduced mass of the honeycomb
block provides fast ramping and reduced settling time (time to achieve thermal
uniformity).
The optical
system, with six filtered LEDs and six filtered photodiodes, collects data from
all wells, detecting up to five targets per well. For single-color FAM and SYBR
Green I, the fast scan option reads single-channel fluorescence in all 96 wells
in just 3 seconds. A channel with an LED filter photodiode combination is
dedicated to FRET singleplex experiments.
The large touch-screen
interface has intuitive graphical programming and displays data traces in real
time. The programmable thermal gradient feature can test eight temperatures at
once to quickly determine the optimal annealing temperature, and the protocol
autowriter quickly optimizes reactions, generating an optimal protocol based on
your polymerase, primers, and product length.
Click Here For Generator
Spare Parts
Condition:
Factory New Sealed
Availability:
In Stock
Ships:
Fast and Reliable Shipping
Factory
New Sealed Without Warranty
