Telemecanique Sensor OsiSense XC Standard limit switch XCKM - steel roller plunger - 1NC+1NO - snap action - Pg11, XCKM | Brand New |

Best Buy Telemecanique Sensor OsiSense XC Standard limit switch XCKM - steel roller plunger - 1NC+1NO - snap action - Pg11, XCKM

Specifications:

Brand: Telemecanique Sensor

Actuator Type: Roller Plunger

Pole and Throw Configuration: DP

Normal State Configuration:NO/NC

IP Rating: IP66

Maximum Current: 10A

Housing Material: Zinc Alloy

Maximum AC Voltage: 240V

Maximum DC Voltage: 250V

Series: OsiSense XC

Action Type: Snap Action

Length: 64mm

Depth: 30mm

Minimum Operating Temperature: -25°C

Width: 63mm

Maximum Operating Temperature: +70°C

Mechanical Life: 20000000Cycles

Country of Origin: France

Product details:

Telemecanique Limit Switches

Introducing Telemecanique XCKM range of limit switches and accessories. These Telemecanique limit switches are the perfect solution for a multitude of applications including escalators, electrical assembly equipment and material handling. A limit switch is commonly made up of an actuator head, switch body and receptacle, predominantly used as part of a control system within industrial applications such as those listed before.

How does a limit switch work?

The limit switches function through a contact proximity sensor device that features an actuator that is mechanically linked to a set of output contacts. When an object comes into contact with the actuator, the device then operates the contacts to make or break an electrical connection.

Model:XCKM
