Mechanical Seal Model 1048-35 | S/PTFE (Stainless Steel/PTFE) | ANSI Pump Seal | Chemical & Water Resistant | Single Spring Design

Mechanical Seal Model 1048-35 | S/PTFE (Stainless Steel/PTFE) | ANSI Pump Seal | Chemical & Water Resistant | Single Spring Design | Brand New |

Mechanical Seal

Model: 1048-35

Explore More Mechanical Items

Condition: Factory New Sealed

Availability: In Stock

Ships: Fast and Reliable Shipping

Brand New Without Warranty

Frequently Asked Questions: Mechanical Seal Model 1045-45 S/PTFE

1. What are the specific dimensions of the Mechanical Seal Model 1045-45?

The Model 1045-45 comes pre-assembled with a 1.125 inch (1-1/8") shaft diameter and 1.75 inch (1-3/4") bore (or stuffing box) diameter. Verify these measurements on your existing pump or equipment for fit prior to buying.

2. What is "S/PTFE" in the product description?

"S/PTFE" designates the primary construction material of this seal. The metallic components (sleeve and spring) are Stainless Steel for corrosion resistance. The bellows and other static seals are made of PTFE (Polytetrafluoroethylene, or Teflon®) for satisfactory chemical resistance.

3. Is this seal compatible with my specific pump model?

The 1045-45 is a very widely used universal seal replacement for the majority of standard ANSI process pumps (Goulds, Durco, ITT, etc.) and other rotary equipment. Compatibility is based on your pump's specific shaft size, bore size, and seal chamber configuration. Cross-reference your pump manual or past seal part number to our specifications at all times.

4. To which chemicals and fluids is this seal resistant?

Because of its Stainless Steel and PTFE construction, this seal has excellent resistance to aggressive fluids of a wide range, including acids, caustics, solvents, salts, and chlorinated water. It is also safe for general water, coolant, and hot water service up to its working temperature. For chemical resistance to a specific chemical, consult a PTFE chemical resistance chart.

5. What is the highest pressure and temperature that this seal can handle?

While an individual rating might be slightly different, a typical S/PTFE mechanical seal like the 1045-45 will be rated 150 PSI (10.3 Bar) and 400°F (204°C). Always stay within these ratings using your operating parameters.

6. Single spring or multi-spring seal?

The Model 1045-45 has a single spring design. This provides a uniform firm closing pressure and is typically simpler to clean and service in viscous fluid application or where clogging is expected to be a problem.

7. What are the face materials of this mechanical seal?

This seal is typically shipped with a standard, very consistent Carbon vs. Ceramic (SiC) face pair. The carbon rotary face is very lubricating, and the ceramic stationary face is very wear-resistant. Verify the actual face materials in product specifications or with our sales personnel.

8. Is the seal bought as single unit or in pair?

This seal is on sale as a whole single unit and is ready to be installed. It comes with the rotary and stationary faces, spring, and all the components needed to assemble together.

9. How does this seal differ from an OEM component?

Our item number 1045-45 is to or exceeds OEM specifications. We provide a direct substitute to be the exact fit, shape, and function as the OEM item, usually at a reduced price, without reducing quality or performance.

10. Do you warranty or guarantee this product?

Yes, we do. We stand behind the quality of our products. This mechanical seal comes with a 1-year limited warranty against material and workmanship defects for the normal use. For all details and terms, please see our warranty policy page.
